1、支吊托架、規格、間距必須符合設計要求，風口閥門等處不得設置吊桿， 風管吊桿必須牢固、位置標高及走向符合設計要求，部件安裝要求方向正確，操作方便，防火閥檢修口必須便于操作。
1, a supporting bracket, specifications, spacing must meet the design requirements, the air valve shall be set at the boom, boom, wind pipe must be firmly position to elevation and meet the design requirements, component installation requirements of the right direction, convenient operation, maintenance of fire valve mouth must be easy to operate.2、本工程小于630mm新風管采用無法蘭風管連接方式，無法蘭加工，無法蘭連接風管的接口采用機械加工尺寸正確，形狀規則，接口嚴密，插條式法蘭連接， 插條用0.8mm鍍鋅鋼板下料咬形。插條兩端壓接兩平面各20mm，風管安裝時把插條與風管連接;風管吊裝好時，用打高分子密封膠密封嚴密.
2, the project is less than 630mm, and the new air pipe can not be connected by Lanfeng pipe. It has no flange processing. The connection between the flanged connection and the air duct is machined with the right size, the shape is regular, the interface is tight, the cuttings flange connection is connected, the cuttings are 0.8mm zinc plated steel sheet undercut bite. The two ends of the bar are pressed to each 20mm of the two plane, and the wind pipe is connected to the wind pipe when the wind pipe is installed. When the wind pipe is hoisted well, the seal is sealed with high polymer sealant.3、風口安裝位置正確，外露部分子整美觀排列整齊一致。粘貼保溫釘前應將風管壁上塵土、油污，將 粘貼劑分別涂抹在風管和保溫釘上，稍干后再將其粘上，保溫釘粘貼密度12只/m2。何溫板下料及鋪設:下料要準確，切割要平齊，搭接要嚴密、平整，散材不 可外露，板材縱橫縫錯開。
3, the installation position of the tuyere is correct, and the appearance of the exserted part is in neat arrangement. The dust and oil stains on the wall of the wind pipe should be removed before sticking the thermal insulation nails. The applicator is applied to the wind pipe and the heat preservation nail respectively. After a little drying, the paste is sticky, and the thermal insulation nail is pasted with a density of 12 /m2. He temperature plate material and laying: the material should be accurate, the cutting should be flat, the lap should be strict and smooth, the material can not be exposed, the plate and the transverse joint are open.4、漏光及漏風量測試

4, leakage and leakage test
5、漏光法檢測應采用光線對小孔的強穿透力，對系統風管嚴密程度進行了檢測方法，采用具有一定強度的光源。如低壓燈lOOW帶保護罩的低壓照明燈，或者其 它低壓光源。低壓風管每lorn不應大于2處且lOOm接縫平均不應大于16處，中壓系統每10m不應超1處，且100m接縫平均不應大于8處，都為合格 漏光，檢測 中如發現條縫形漏光的應及時進行密封處理。
5, the leakage detection method should be used for small strong light penetration, the wind system heavily tested method, using safe light with certain strength. Such as low voltage lamp lOOW with protective cover of low voltage light, or other low voltage light source. Low pressure air pipe of each lorn should not be greater than 2 and the average lOOm joint should not be greater than 16, the medium voltage system every 10m should not exceed 1, and the average 100m joint should be less than 8, are qualified for light leakage is found in the detection of slot leakage should be promptly sealed.6、漏風量測試應采用檢驗合格的專用測量儀表或采用符合現行標準(流量測量節流裝置)規定的計量元件搭設的測量裝置。漏風管測試裝置可采用風管 式或風室式。風管式測試裝置采用孔板作計量元件，風室式測試裝置采用噴嘴作計量元件，后測出的實測值與設計給定的數值不應小于10%為合格。
6, the test of leakage volume should be made by a qualified special instrument or a measuring device that fits the current national standard (flow measurement throttling device). Wind pipe type or wind chamber type can be used for air leakage test device. The air duct test device adopts orifice plate as measuring element, and the wind chamber test device adopts nozzle as measuring element. Finally, the measured value is not less than 10%, which is qualified for designing the given value.
本文由濟南排煙罩進行編寫，想要了解更多的產品及更詳細的精彩內容，請關注我們的網站： http://m.bjhgf.com您的惠顧是對我們很大的支持。
This article is written by the Ji'nan exhaust hood. If you want to know more products and more detailed highlights, please pay attention to our official website: http://m.bjhgf.com, your patronage is a great support for us.
